Simple Distillation setup
.jpg)
- Glass Distillation Tank – 1 liter capacity
- Condenser : Condenser tube type
- Condenser glass tank
Steam distillation setup
- SS Distillation Vessel jacked type insulated with ceramic wool & cladding with aluminum foil
- Steam generator : Material SS provided with pressure gauge & level indicator
Packed Bed Distillation column
- Distillation tank made as Stainless steel
- Steam generator with pressure gauge, safety valve and indicator
Liquid Liquid Extractor
- Two numbers of Rotameter to measure the flow rate
- SS water storage tank
- Extractor setup fixed on frame
Vacuum Dryer
- Oven Size : 10 liter (300 X 300mm)
- Vacuum dryer
- Vacuum pump
- Digital Controller
- Rugged powder coated Setup
Tray Dryer
- Electric Air blower to circulate the air
- SS Chamber with transparent door
- Electric heater with dimmer stat
- Hand valve to control the flow rate
Rotary Dryer
- Long revolving cylindrical shell slightly inclined towards the outlet.
- Air from a blower passes through a heating chamber to dry the air.
- Wet feed enters from one end of the cylinder
Ion Exchange Column
- Two No’s of glass column mounted in vertical with anion and cation
- Rotameter to monitor the flow rate
- Pump is provided for flow circulation.
Rotating Disc Contactor
- SS collecting tank with side level indicator
- Rotameter (2 No’s) to monitor the NaOH and Ethyl Acetate flow rate
- One glass column mounted in vertical
- Variable speed operation
Water Cooling Tower Apparatus
- Cooling tower provided to avoid the escape of water.
- Instant water heater to heat the flow of water
- Blower to blow the air through cooling tower
Absorption Column Setup
- Absorption column setup mounted on vertical (Glass / Acrylic)
- Rotameter mounted on panel
- Air filter regulator provided
- SS Chamber 1 liter capacity
Surface Evaporation Setup
.jpg)
- Weighing Scale
- Digital Temperature Controller
- Temperature sensor : Thermocouple / RTD Type
- SS process tank
Adsorption Studies using Conical Flask
- Centrifuged Blower to circulate the air
- Air Heater With Insulation
- Heating Chamber
- Vertically Mounted Glass Beaker Setup
Single Stage Leaching
- Extraction Column
- Conveyor suitable size solid feed hopper
- Rotameter to monitor the flow rate
- Feed tank to store the Liquid
